Specifications
Prod Model: |
TTR 170SX RACING |
Markets: |
North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe |
Engine: |
K170 Manual Clutch |
Max. Power(Kw/Rpm): |
11.8kw/8500 Rpm |
Max Torque(N.M/R/Min): |
15.0n.M/7000 Rpm |
Start: |
Kick |
Tyres: |
Front 70/100-17;Rear 90/100-14 |
Front Shock: |
Adjustable USD Fork Travel 110mm |
Rear Shock: |
Adjustable Travel 59mm |
Fuel Capacity: |
5.1L |
Type: |
Dirt Bike |
Displacement: |
126-250CC |
Engine Type: |
4-Stroke |
Fuel: |
Gas / Diesel |
Certification: |
CE |
Condition: |
New |
Product Description
Engine:K170 Manual Clutch | Frame:Design by Kayo |
Bore*Stroke:62mm*56mm | Handle Bar :Alloy |
Compression Ratio:10.5:1 | Lever:Design by Kayo |
Max Power:11.8KW/8500 rpm | Rim:Alloy(Front 1.6-17;Rear 1.85-14) |
Max Torque:15.0N.M/7000 rpm | Tyres:Front 70/100-17;Rear 90/100-14 |
Ignition:CDI | Front Fork:Adjustable USD Fork travel 110mm |
Starter:Kick | Rear Shock:Adjustable travel 59mm |
Transmission:15T-41T KMC428 | Carburetor:Mikuni |
Wheel Base:1210mm | Swing Arm:Alloy L=425mm |
Seat Height:840mm | Brake:Disc |
Ground Clearance:340mm | Fuel Capacity:5.1L |
Dry Weight:77kg | Plastic:TTR |
|
Packing Dimensions:1560*380*735mm |
20'GP:63 PCS |
40'HQ:153 PCS |
1,Kayo made the first pit bike for kids in China(2001);
2,Kayo made the first racing pit bike for children in China(2008);
3,Kayo made the first self-developed champion pit bike in China 150 class(2009);
4,Kayo made the first high-power champion motocross with NC250 engine in China(2010);
5,Kayo made the first road racing motorcycle in China(2011);
6,Kayo made the first EFI racing motocross-K6 in China(2015).
