Specifications
Prod Model: |
SNOWMOBILE0002 |
Product Description
Type / Displacement / ml Four-stroke, 244. 3ml
Cylinders Single
Cooling Liquid
Bore & Stroke / mm 72x60
Ignition CDI
Rated Power and Rotate Speed 10. 5KW/6000r/min (14. 3HP)
Max Torque and Rotate Speed 17. 6N. M/5500r/min
Exhaust Rear Exhaust
Clutch / Transmission V-belt CVT Automatic
Brake Type Rear Disk brake
Chassis
Front Suspension Independent, Double A-arm
Ski Type stainless steel
Rear Suspension parallelogram swing
Dimensions
Overall Length / mm 2100mm
Overall Width / mm 950mm
Overall Height / mm 1050mm
Track/Width x Length/mm 198x1728
Estimated Dry Weight 150kg
Ski Stance (ctr. To ctr. ) in. 800mm
Fuel Capacity / L 7. 5L
Fuel Type Regular Unleaded
Engine Oil Type #20
Features
Electric Start Standard
Windshield Standard
Max speed 60 km/h
Warranty 1 Year (Limited Factory Warranty)
