Specifications
Product Description
Motor power: 500W, CPU motor
Climbing angle: 15-20
Torque: 32-55 Nm
Front brake: Drum brake
Rear brake: EABS (electric absorption braking system, foot brake)
Speed: 25-35Km/H (13.6-19.8mph), double speeds
Battery capacity: 48V17AH
Other parameter
Body size (L*W*H): 170*64.5*101cm (67*25.3*39.7ins)
Wheel size: 10*3.00
Loading: 200Kg (441 lbs)
Seat above ground: 72cm (28.3 ins)
N. W(no battery): 54Kg (119 lbs )
Weight of battery: 26Kg (57 lbs)
G. W: 95Kg (209 lbs)
Packing (L*W*H): 179*55*113cm
Container: 24PCS/20GP, 52PCS/40GP, 52PCS/40HQ
Battery name: Sealed Lead-acid battery (Maintainable)
Run distance: 45-60Km
Charge time: 3-8 H
Charger input: AC100-240V, BM-online (battery maintained while charging)
