Electric Mobility Scooter with Samsung Battery

Electric Mobility Scooter with Samsung Battery
Price: US $ 880-1580/Piece
Trade Terms: FOB,EXW,CIF
Min Order: 1/Piece
Pay Type: L/C,T/T,Western Union,Money Gram

Specifications

Prod Model: ESOII
Markets: North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe
Application: Tour, Patrol Advertise, Lease, Transport Tool
Max.Speed: 20km/H, Three Speed Modes
Package: Wooden Case or Double Carton Box
Gross Weight: 68kg
Max.Load: 150kg
Name: off Road Electric Skateboard
Type: 2 Wheels
Board Material: Aluminium Alloy
Wheel Kind: Sliding
Customized: Customized
Condition: New
Age: All Age
Kind: Electric Scooter
Deck Material: Aluminium Alloy
Usage: Entertainment
Color: 7 Colors Available.

Product Description


electric mobility scooter with Samsung battery

Working principle of off road electric skateboard
Based on the basic principle of "motion stability", that is to say, vehicle's automatic balance ability, ESOI can judge the position, status of vehicle by its built-in precise solid-state gyroscope and then drive its motors to balance the vehicle after receiving the commands from high-speed CPU inside.

Driving ability of off road electric skateboard
With 2 strong motors, 800W per motor (2 motors can be 1600W), FreeGo 2 wheel scooter can move at the speed up to 18 km/h. Through a smart transmission, the ESOI drives 2 PCS of 16-inch high strength vacuum tires which makes it moves stable and comfortable no matter it is indoor or outdoor

The source of power
The power source of ESOI comes from the 2 rechargeable powerful batteries (12V@14AH) which can work for 2.5 hours and moves 30--35 km for one time fully charge.

Feature of off road electric skateboard:
1. New steering mechanism, more stable and comfortable, faster response
2. Updated process motherboard, more safe and easy to be controlled
3. Waterproof
4. Advanced design for steer and handle, beauty and fashion
5. More exquisite and light steering mechanism, more flexible turning
6. New model pedal with 4 detecting switch. Driver will not fall down in driving.
7. Adjusting big power importing motor. Max power of single wheel can achieve 800W, easy to climb continuously 30 degree slope.
8. Siren alarm, reminding the statue of scooter
9. GPS tracking is optional
10. High quality wheel with smooth racing tire.

Performance Parameter of off road electric skateboard

Max speed: 11.5 mph / 18 km/h
Dimension: 43*43*68 cm
Max load: 240 lbs / 110 kg
Battery: Two power lead acid
Motor: Two import DC Motor, DC servo drives
Wheel: 12 in / 26 cm Black Aluminum Rim
Tire: 17 in / 43 cm vacuum smooth
Height of footplate: 10in/26cm
Net Weight: 43 kg
Max distance: 30 km depends on terrain and driving skill

Packing list (Standard kits/parts)

Handle: 1 PC
Key: 2 PCS
User manual: 1 PC
Driving handle: 1 PC
Extra fuse: 4 PCS
Pedal mat: 2 PCS
Fender: 2 PCS
Tire: 2 PCS
Battery charger: 1 PC

Packing of off road electric skateboard
Inner: Carton, Outer: Plywood box
Gross weight: 58kg/carton
CTN demission: 47*47*74cm
Volume: 0.18cbm
135PCS/1container (20#)
 Net Weight56kg
 Dimension91*54*72 cm
 Max. cruise speed20km/h
 Max. load150kg
 Max. mileage30-35km
 Max. climb capability30 degree
 Min. turning radius0 degree
 Charging time6-8h
 BatteryPB, 36V, 48Ah
 Voltage100v-240v
 Max. power2000w (2*1000w/pc)
 Life of battery1-3 years
 Tire19inches vacuum,anti pucture
 WheelSuperior integrated aluminum magnesium alloy
 Height of handle800-1100 mm adjustable
 Height of footplate10inches
 Specifications of footplate11.5*25 in
 Max. height above ground120mm
 Standard pressure250kpa
 Colors7 colors available
 CertificationsCE, FCC, ROHS
