Specifications
Prod Model: |
GBT-E7015 |
Markets: |
North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe |
Electric ATV (Gbt-E7015): |
Electric ATV (Gbt-E7015) |
Transmission System: |
Chain Drive |
Transmission Type: |
Automatic |
Certification: |
CE |
Fuel: |
Electric |
Structure: |
Without Door |
Maximum Speed: |
<50 km/h |
Brake Type: |
Disc Brake |
Engine Type: |
Electric |
Displacement: |
750W |
Product Description
CS-E7011
Battery Specification: 48V/20AH, 48V/20AH, 48V/20AH
Motor Specification: 48V/500W, 48V/800W, 48V/1000W
Rated speACS-E7015
Battery Specification: 36V/12AH, 36V/12AH, 48V/20AH
Motor Specification: 36V/500W, 36V/800W, 48V/1000W
Rated speed: 533, 566, 600
Rated power ( W ): 500W± 10%, 800W± 10%, 1000W± 10%
Controller specifications: 36V/500W, 36V/800W, 48V/1000W
Charging requirements: AC80-240V 50-60Hz 36V/MAX1.6A, AC80-240V 50-60Hz 48V/MAX1.8A
Charge time ( H ): 8-9, 8-9, 11-13
Brake type: The former hub brakes, rear a single disc fluid brake
Tire size: Front, rear: 145/70-6
N. W. /G. W. (kg): 73/85, 73/85, 74/86
Product size(mm): 1270× 740× 850
Packing size(mm): 1160× 650× 570
Transmission category: Chain drive
Loading capacity: 54PCS/20'FT, 124PCS/40'GP, 136PCS/40'HQ
Packaging category(mm): Hob(1140*635*570)+Carton(5 Layers)
ED: 533: 566: 600
Rated power ( W ): 500W± 10%, 800W± 10%, 1000W± 10%
Controller specifications: 48V/500W, 48V/800W, 48V/1000W
Charging requirements: AC80-240V 50-60Hz 48V/MAX1.8A
Charge time ( H ): 8-9, 8-9, 11-13
Brake type: The former hub brakes, rear a single disc fluid brake
Tire size: Front, rear: 145/70-6
N. W. /G. W. (kg): 95/107
Product size(mm): 1570× 800× 950
Packing size(mm): 1240× 770× 630
Transmission category: Chain drive
Loading capacity
Packaging category(mm): Hob(980× 560× 430)+Carton(5 Layers)
