Home Jinhua Bojo Technology Co., Ltd. EEC 550cc 4 Wheel Drive Motorcycle
EEC 550cc 4 Wheel Drive Motorcycle
| Price: | US $ 3800-3850/Piece |
|---|---|
| Trade Terms: | FOB,CFR,CIF |
| Min Order: | 2/Piece |
| Pay Type: | L/C,T/T,Western Union |
Specifications
| Prod Model: | MC-392 |
|---|---|
| Markets: | North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe |
| Engine: | 4 Stroke, V-Twin Cylinder, Sohc |
| Color: | Red/Yellow/White/Black/Grey |
| Warranty: | 6 Month |
| Ignition Type: | Cdi |
| Vehicle Dimensions: | 2260 X 1180 X 1270mm |
| Front Tire Spec: | At26X9-12 |
| Rear Tires Spec: | At26X11-12 |
| Fuel Tank Capacity: | 13.5L |
| Item Name: | 600cc ATV |
| Battery Spec: | 12V,12ah |
| Transmission Type: | Automatic |
| Engine Type: | 4 Stroke |
| Structure: | Without Door |
| Displacement: | >400CC |
| Transmission System: | Chain Drive |
| Fuel: | Gas / Diesel |
| Brake Type: | Disc Brake |
| Maximum Speed: | >75 km/h |
| Power: | >1000W |
| Certification: | EEC |
| Condition: | New |
| Brand: | Bode |
Product Description
EEC 550CC 4 WHEEL DRIVE MOTORCYCLEThis Vehicle come with EEC approved for on road legal use in Europe.
ENGINE TYPE: 4 Stroke, V-Twin Cylinder, SOHC
Engine Cooling: Liquid-Cooled
MAX. POWER(KW/rpm): 26.5KW/7000rpm
Standard Power: 25KW/6500rpm
MAX. TORQUE(NM/rpm): 45N. M/5500rpm
MAX. SPEED: ≥ 85Km/h
BORE STROKE: 72.5mm x 66.8mm
DISPLACEMENT: 552ml
COMPRESSION RATIO: 10.3: 1
Fuel System: Electronic Fuel Injection
IGNITION: Direct current electronic ignition
SPARK PLUG: DR8EA
STARTING: Electric Start
TRANSMISSION: CVT
BRAKE FRONT/REAR: Disc Brake
BRAKE REAR: Disc Brake
BRAKE DISTANCE: 7m/30km/h
FRONT SUSPENSION: Macphersan Independent
REAR SUSPENSION: Double Wishbone
SHOCK ABSORBER(F/R): Spring and Damp Shock Absorbor
SHOCK ABSORBER: Spring and Damp Shock Absorbor
BATTERY: 12V/14AH
ENGINE OIL: 1.5L
TRANSMISSION OIL: 0.8L
REAR OIL: 0.3L
FUEL: 93# Unleaded Gasoline
FUEL CAPACITY: 13.5L
Climbling capacity: 25°
TURNING RADIUS: 3400mm
FRONT TIRE: AT26x9-12
REAR TIRE: AT26x11-12
OVERALL: 2260 x 1180 x 1270mm
WHEELBASE(mm): 1460mm
GROUND CLEARANCE: 300mm
NET WEIGHT(kgs/lbs): 355kgs
Standard Colors: Red, Blue, Black.
