Specifications
Prod Model: |
XT-FL447 |
Markets: |
North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe |
Wheel Material: |
Rubber and Steel |
Body Material: |
ABS and Steel |
Color: |
Options Available, as Custoner's Requireme |
Tire Size: |
Front Wheels: 10" Rear Wheels:14" |
Product: |
Disabled Scooter |
Fuel Type: |
Electric |
Foldable: |
No |
Usage: |
Home Care, Hospital, Outdoor, Clinic |
Function: |
Folding, Removable, Detachable |
Theory: |
Movement Therapy |
Product Description
Specifications
Disabled Scooter
Quick & easy folding mechanism
Front protection bumper
Comfortable and Convenient Adjustable Seat
Arm rests
Disabled Scooter - Voyager 8:
Dimensions: 1300 x620 x 980mm
Packing size: 1490 x 740x 1040mm
Ground clearance: 90mm
Max. Forward speed: 12km/h
Max. Backward speed: 6-8km/h (optional)
Climbing capability: 12 degrees
Turning radius: 1.6 m
Motors: 24V 450W
Battery: 12V 38Ah x 2 Lead acid
Charger: 24V4A battery charger
Charge time: 10-12hrs Recommended
Net Weight: 92kg(including 2 batteries: 27.6kg)
Gross Weight: 111kg
Front Wheels: 10" Rear Wheels: 14"
Load: 140Kg
Approximate Running Distance on full charge: 45Km (terrain dependant).
Accessories Available: Dust cover\front basket cover
Specification for Wisking4017 |
Overall dimension |
1540*720*1280mm |
Front tire / Rear tire |
16" air tire / 16" air tire |
Weight capacity |
150kg |
Controller |
PG (Imported from UK) 140A |
Motor |
24V/1200W |
Battery |
12V/55AH x 2 |
Battery weight |
17 kg x 2 |
Battery dimension (l*w*h) |
230*138*226mm x 2 |
Charger |
24V/6A |
Recharge time |
8-10 hrs |
Gross weight |
150kg |
Net weight (with batteries) |
130kg |
Package |
1pkg |
Package size |
160*75*101cm |
Range |
up to 40km per battery charge |
Incline capability |
15 degrees |
Turning radius (min) |
1.2 m |
Ground Clearance |
12 cm |
Max. forward speed |
17km/h |
Qty of 20' FCL |
20pcs |
Note: 55AH,75AH,100AH battery can be optional for Wisking4017 |
