Disabled Scooter, Handicapped Mobility Scooter (XT-FL447)
| Price: | US $ 600-1800Set |
|---|---|
| Trade Terms: | FOB |
| Min Order: | 1Set |
| Pay Type: | L/C,T/T,Western Union |
Specifications
| Prod Model: | XT-FL447 |
|---|---|
| Markets: | North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe |
| Wheel Material: | Rubber and Steel |
| Body Material: | ABS and Steel |
| Color: | Options Available, as Custoner's Requireme |
| Tire Size: | Front Wheels: 10" Rear Wheels:14" |
| Product: | Disabled Scooter |
| Fuel Type: | Electric |
| Foldable: | No |
| Usage: | Home Care, Hospital, Outdoor, Clinic |
| Function: | Folding, Removable, Detachable |
| Theory: | Movement Therapy |
Product Description
SpecificationsDisabled Scooter
Quick & easy folding mechanism
Front protection bumper
Comfortable and Convenient Adjustable Seat
Arm rests
Disabled Scooter - Voyager 8:
Dimensions: 1300 x620 x 980mm
Packing size: 1490 x 740x 1040mm
Ground clearance: 90mm
Max. Forward speed: 12km/h
Max. Backward speed: 6-8km/h (optional)
Climbing capability: 12 degrees
Turning radius: 1.6 m
Motors: 24V 450W
Battery: 12V 38Ah x 2 Lead acid
Charger: 24V4A battery charger
Charge time: 10-12hrs Recommended
Net Weight: 92kg(including 2 batteries: 27.6kg)
Gross Weight: 111kg
Front Wheels: 10" Rear Wheels: 14"
Load: 140Kg
Approximate Running Distance on full charge: 45Km (terrain dependant).
Accessories Available: Dust cover\front basket cover
| Specification for Wisking4017 | |
| Overall dimension | 1540*720*1280mm |
| Front tire / Rear tire | 16" air tire / 16" air tire |
| Weight capacity | 150kg |
| Controller | PG (Imported from UK) 140A |
| Motor | 24V/1200W |
| Battery | 12V/55AH x 2 |
| Battery weight | 17 kg x 2 |
| Battery dimension (l*w*h) | 230*138*226mm x 2 |
| Charger | 24V/6A |
| Recharge time | 8-10 hrs |
| Gross weight | 150kg |
| Net weight (with batteries) | 130kg |
| Package | 1pkg |
| Package size | 160*75*101cm |
| Range | up to 40km per battery charge |
| Incline capability | 15 degrees |
| Turning radius (min) | 1.2 m |
| Ground Clearance | 12 cm |
| Max. forward speed | 17km/h |
| Qty of 20' FCL | 20pcs |
| Note: 55AH,75AH,100AH battery can be optional for Wisking4017 | |
