Specifications
Markets: | North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe |
---|---|
Certification: | EEC |
Starting System: | Kick Start and Electric Start |
Engine: | 4 Stroke |
Displacement: | 51-125CC |
Product Description
OtherEngine | ||
Type | Suzuki model 124cc, single-cylinder, 4-stroke, air- cooled | |
Bore x Stroke (mm) | 57 x 48.8 | |
Compression Ratio | 9.2: 1 | |
Ignition | CDI | |
Transmission | 5-speed gear shift | |
Starting system | Electric | |
Max power | 8.3kw/9500r/min | |
Max torque 8.1Nm/8500r/min | ||
Max speed ≥ 95km/h | ||
Drive | chain | |
Chassis | ||
Suspension/Front | Spring oil damper | |
Suspension/Rear | Swing-arm spring oil damper | |
Brakes/Front | Disc type | |
Brakes/Rear | Drum type(DISC/DISC) | |
Tires/Front | 2.75-21 (race tire: 110/70-17) | |
Tires/Rear | 4.10-18 (race tire: 130/70-17) | |
Dimensions | ||
Length x Width x Height | 2115mm x 830mm x 1140mm | |
Wheelbase | 1405mm | |
Seathigh 870mm | ||
Dry Weight | 123kg | |
Fuel Capacity | 10.6L |
