Specifications
Prod Model: |
HD50QT-3/HD125T-3/HD150T-3 |
Markets: |
North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe |
Max Speed: |
>50km/h |
Certification: |
COC |
Engine: |
4 Stroke |
Maximum Loading Capacity: |
≥120kg |
Fuel Tank Capacity: |
>8L |
Folded: |
Unfolded |
Displacement: |
50cc-150cc |
Max Power: |
6.5kw/7000rpm |
Product Description
Specifications: Cooling System Air Cooled
Compression Ratio 10.5:1
Fuel feed 90#
Max Power( Kw/rpm) 2.5/7500
Max Torque(N.M/rpm) 2.8/5500
Max Speed 50 kmph
Ground clearance 130 mm
Fuel consumption 2.0L/100KM
Drive Train CVT
Ignition CDI
Transmission Belt
Fuel tank capacity 5L
Starting System Electric+kick start
Front Brakes Disc brake
Rear Brake Drum brake
Front suspension Hydraulic Suspension
Rear suspension Hydraulic Suspension
Front tires 120/70-12
Rear tires 120/70-12
Wheel Base 1340 mm
Seat Height 840 mm
Payload 75kg
Net Weight 93 kg
Gross Weight 113 kg
Packing type Steel + Carton
Packing size 1850×570×860
20' container 24 units
40' HQ container 75 units
