Specifications
Prod Model: |
46AT2007-B1302 |
Markets: |
North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe |
Wheel Number: |
4 |
Piston Displacement: |
200cc |
Fuel Tank: |
4.5 Liters |
Fuel Type: |
Unleaded Gasoline with Octane No. 91 or Higher |
Starting System: |
Electric |
Drive Train: |
Chain |
Ignition Method: |
Cdi |
Output: |
Max. 10.0kw/7, 500rpm |
Torque: |
13.5n.M/6, 500rpm |
Brakes: |
Front: Drum, Rear: Disc |
Transmission System: |
Chain Drive |
Transmission Type: |
Automatic |
Certification: |
DOT |
Engine Type: |
4 Stroke |
Fuel: |
Gas / Diesel |
Displacement: |
200CC |
Structure: |
Without Door |
Maximum Speed: |
<50 km/h |
Brake Type: |
Disc Brake |
Product Description
ATV
CE Approved 200CC ATV Equipped with Powerful Water Cooling Engine
AT2007-B
Key Specifications:
1. Wheel number: 4
2. Piston displacement: 200cc
3. Fuel tank: 4.5 liters
4. Fuel type: Unleaded gasoline with octane no. 91 or higher
5. Engine type: Single cylinder, water-cooled
6. Starting system: Electric
7. Drive train: Chain
8. Ignition method: CDI
9. Output: Max. 10.0kw/7, 500rpm
10. Torque: 13.5N. M/6, 500rpm
11. Brakes: Front: Drum, rear: Disc
12. Transmission: Four gears with reverse and manual clutch
13. Wheel side: Front: 21X7-8, rear: 20X9.5-8
14. Reserve: Inner reverse gear
15. Min. Ground clearance: 125mm
16. Max. Load: 100kg/220lbs
17. Max. Speed: >60km/h, 37miles/h
18. Climbing ability: <20 degrees
19. Wheelbase: 1, 050mm
20. Seat height: 780mm
Package: Iron cage with carton outside
21. Net weight: 150kgs/330lbs
22. Gross weight: 173kgs/381lbs
23. Carton size: 158X84X76cm/1PC
24. Container: 28PCS/20', 57PCS/40', 67PCS/40'HQ
Special Features:
Chain driving power transmission
CDI ignition mode
Powerful water cooling engine
Minimum Order quantity: 5PCS
