Specifications
Product Description
Key Specifications/Special Features:Engine Type: 4-Strokes, Air Cooled Fully-Automatic
Transmission System: Shaft Drive
Bore x Stroke(mm): 71x 58
Piston Displacement: 229.6
Maximum Power(kw/r/min): 10/6000-7000
Maximum Torque(N. M. /r/min): 15/5500-6500
Starting System: Electric/recoil backup
Transmission: 5 Speeds, semi-automatic
Seat Height(mm): 810+/-20
Min Turning Radius(mm): 2900
Ground Clearance: 155
Brake(Front/Rear): Drum/Drum
Tyre, Fromt: AT23 X 7-10
Tyre, Rear: AT22 X 10-10
Ignition Type: C. D. I
Fuel Tank Capacity(L): 12
Front Suspension: Independent front suspension
Rear Suspension: Swing arm
Parking Brake: Mechanical Lock
Battery: 12V-14Ah
Max Load Capacity(kg): 165
Engine Oil Capacity(L): 1.6
Gear Oil Capacity(L): 0.27
Dry Weight(kg): 220
Rider Capacity: 1 Person
Wheel Base: 1160
Overall Height(mm): 1160
Lubrication: Pressuring splash
Overall Length(mm): 1940
Overall Width(mm): 1050
Compression Ration: 8.7: 1
Cylinder Arrangement: Single Cylinder
Container: 15pcs/20', 30pcs/40'
