Specifications
Product Description
Engine Type One cylinder, 4 stroke, air-cooledBore*Stroke (mm) 47. 0*41. 5
Piston Displacement (cc) 49
Compression Ratio 8. 8: 1
Max. Power (kw/rpm) 3. 8/8000
Max. Torque (N. M/rpm) 4. 5/6000
Transmission System Chain drive
Ignition Type C. D. I
Starter System Electric
Transmission Auto 2 Speed
L*W*H (mm) 1335*730*780
Wheel Base (mm) 830
Ground Clearance (mm) 110
Dry Weight (kg) 74
Brake (Front/Rear) Drum/Disk
Tyre, Front AT16X8-7
Tyre, Rear AT16X8-7
Fuel Tank Capacity (L) 3. 2
Engine Oil Capacity (L) 0. 65
Max. Load Capacity (kg) 45
Max. Speed(km) 35
Battery(V/Ah) 12V/5Ah
Loading(20'/40') 36/108
