Specifications
Product Description
Rated line pull: 3000lbs(1361kgs) Single-line
Motor: Permanent Magnet motor input 1.0kw/1.2hp
Control: Remote switch 3.7m lead
Gear train: 3 Stage Planetary
Gear ratio: 153: 1
Braking action: Mechanical and Dynamic
Drum size(Dia. X L): 30.5mm x 73mm
Cable (Dia. X L): 5.4mm x13m
Mounting bolt pattem: 79.3mm
