ATV (SN09-200CC)

Specifications

Prod Model:	SN09-200CC

Product Description

Features:
1) Dimensions (L x W x H) (mm): 1, 990 x 1, 050 x 1, 060
2) Wheelbase (mm): 1, 160
3) Engine type: Single cylinders, air-cooled, four-stroke 200CC
4) Start mode: Electric / electric manual

5) Power (kW / rpm): 9.9 / 6, 500
6) Max. Torque (N. M / rpm): 14 / 6, 000
7) Min. Ground clearance (mm): 135
8) Max. Speed: Y90

9) Dry weight (kg): 220
10) Transmission mode: Chain
11) Break type (F / R): Disc / disc
12) Battery: 12V, 14Ah

13) Climbing degree: 30
14) Tank capacity (L): 12
15) Front hanging: Arm swing
16) Rear hanging: Integral

17) Tire:
A) Front wheel drive: 23 x 7-10
B) Rear wheel: 22 x 10-10
18) Cylinder diameter x journey (mm): 71 x 58
19) Displacement (ml): 200
20) Shift gear: Five gears, automatic

21) Height of seats (mm): 820
22) Mini turning radium (mm): 2, 900
23) Parking trig: Mechanic lock
24) Ignition mode: CDI

25) Loading capacity (kg): 180
26) Engine oil (L): 1.6
27) Gear wheel oil (L): 0.25
28) Person: 2

29) Lubrication: Press splash
30) Compression proportion: 8.7: 1
31) Gas cylinder number: 1
32) Parking dimension (mm): 1, 940 x 1, 040 x 880

Conveyance:
Qty/20' GP: 12 units
Qty/40' HQ: 30 units
