ATV (GH-ATV50-2)

Specifications

Prod Model:	GH-ATV50-2

Product Description

1) Engine type: four-stroke, one cylinder, air-cooled
2) Engine displacement (cc): 110
3) Bore x stroke (mm): 52.4×49.5
4) Max. power (kW/rpm): 4.7/7,500
5) Max. torque (N.m/rpm): 6.5/5,500
6) Compressing ratio: 8.8: 1
7) Top speed (km/h): 65
8) Oil tank (L): 2 (90# oil and up)
9) 100 (km)/oil (L): <1.9
10) Available engine (cc): 110
11) Start mode: electric start
12) Battery: 5A, 12V
13) Transmission mode: chain
14) Brake system: rear disc brake
15) Shock system: hydraulic shock absorber
16) Shift speed type: no
17) Clutch mode: automatic
18) Dimensions (L x W x H) (mm): 1,460×930×1000
19) Tire dimension (front / rear): 16×8-7
20) Seat height (mm): 68
21) Load capability: 120kg/250lbs
22) Circulator type: PZ19
23) Starter battery type: GT5-3
24) Colors: red / blue / black / orange / yellow / green

Outer packing:
Carton dimensions: 1310×850×630mm
N.W.: 96kg
G.W.: 105kg

Conveyance:
Qty/20' GP: 45pcs
Qty/40' GP: 92pcs
Qty/40' HQ: 108pcs
