ATV (CK200S-2C)

Specifications

Prod Model:	CK200S-2C

Product Description

CK200S-2C

Main parameter as well as function index
Length X Width X Height (mm): 1850 X 980 X 1080
Wheel Base(mm): 1110
Engine Type: Single Cylinder; Air-cooling; Four stroke
Start Mode: Electric
Power (Kw/r/min): 10.0/7500r/min
Max Torque (N. M/r/min): 13.5/6500r/min
Max Speed(km/h): >60 or =60
Mini Ground Clearance (mm): 150
Dry Weight(Kg): 150
Transmission Mode: Chain
Break Type(F/R): Drum/Disc
Specification: 12V9Ah
Climb Degree: >20 or =20
Tank Capacity (L): 4
Front Hanging: Double Arm-swing
Rear Hanging: Integral
Specification of tyre: Front-wheel drive: 19 X 7-8
Rear wheel: 18 X 9.5-8
Cylinder Diameter*Journey(mm): 63.5 X 62.2
Displacement (ml): 197
Shift Gear: Four gear with reverse gear
Manual clutch
Height of seats(mm): 800
Mini Turning radium(mm): 2400
Parking Trig: Mechanic Lock
Ignition Mode: CDI
Loading Capacity(kg): 150
Engine Oil (L): 1.0
Gear Wheel oil (L): 0.2
Person: 1
Lubrication: Press Splash
Compression Proportion: 9.2: 1
Gas Cylinder number: 1
Parking Dimension(mm): 1490 X 840 X 770
Quantity of loading:
20' GP: 29 units
40' GP: 64 units
40' HQ: 66 units
