ATV(ATV250-5)

Specifications

Product Description

Engine: One cylinder air-cooled 4-stroke
Dispalcement(cc): 229.6ml
Cylinder dia x work stroke: 71x58mm
Compressing ratio: 8.7: 1
Max speed(km/h): 85km/h
Max load(running smoothly): 145kg
Rated power (kw/r/min): 10kw(7500r/min)
Max torque n. M/(r/min): 15n. M(6000r/min)
Fuel tank: 12l
Carburetor type: Plug carburetion
Seat height: 780mm
Tansmition: Shaft
Drive model: 5 speed forword/1 reverse
Drive ratio: 3.318/2.833/1.789/1.318/1.040/0.821/4.414
Clutch: Wet centrifugal automatic
Wheel shape: Steel plate
Oil consumption: 2.7l/100km
Ignition means: Cdi
Oil ignites: Rq-90 gb17930-1999
Brake front: Disc, rear: Drum, foot control or left handle control
Braking: 7m/30km/h
Start: Electric or hand
Lubrication oil: Sae20w40, sae10w30, sae5w30
Lubrication oil amount: 1.6l
Lubricate means: Press/splash
Sparking plug: D7rtc
Battery: 12v12ah
Mounting: 30 degree
Front tire: At22x7-10/20kpa
Rear tire: At22x10-10/25kpa
Wheelbase: 1160mm
Ground clearance: 155mm
Product size(cm): 1940x1050x1160mm
Nw(kg): 220kg
Gw(kg): 250kg
Pcs/20': 12
Pcs/40': 24
