Home Zhejiang Sm Appliance Co., Ltd. ATV(4 Stroke,50cc )
Specifications
| Prod Model: | 4 stroke,50cc |
|---|
Product Description
Engine: 49cc, single cylinder, 4-stroke, air-cooled2) Bore x stroke: 39 x 41. 4mm
3) Max. power: 2. 5kW / 8, 500rpm
4) Max. torque: 3. 0N. m / 6, 500rpm
5) Min. fuel consumption: no less than 450g/kw. h
6) Start mode: electrical transmission
7) Mode: chain
8) Brake mode: rear disk brake
9) Shift type: auto gear
10) Min. turning radius: 2, 300mm
11) Climbing degrees: no less than 18
12) Lamp: two head lights, one rear light
13) Seat height: 540mm
14) Min. ground clearance: 70mm
15) Top speed: 40km/h
16) Tire dimensions (front / rear): 145/70-6 / 145/70-6
17) Cover material: PP
18) Dimensions (L x W x H): 1, 150 x 690 x 700mm
19) Colors: red, yellow, blue, green, black
Outer packing:
Carton dimensions: 1, 170 x 700 x 690mm
N. W.: 63 kg
G. W.: 88 kg
Conveyance:
Qty/20' GP: 45pcs
Qty/40' GP: 90pcs
Qty/40' HQ: 120pcs
