Specifications
Prod Model: |
HDG970E-4Q |
Markets: |
North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe |
Brake: |
Hydraulic Disc, Right Foot Control |
Engine: |
4cylinder,4-Strokes,Water Cooled |
Container Load: |
4PCS/20ft;10PCS/40hq |
Vehicle Size (Mm): |
3020×1840×1650 Mm |
Carton Size: |
2.8×1.6×1.22m |
Gear: |
Automatic Clutch,Five Speeds |
Age: |
Adults |
Transmission: |
Shaft |
Start-up: |
Electric |
Certification: |
DOT |
Maximum Speed: |
>90 km/h |
Kind: |
Gear |
Condition: |
New |
Usage: |
Go Kart |
Color: |
Red,Yellow,Blue,Black,White |
Displacement: |
1000cc |
Product Description
Engine type LJ465Q-1ANE1 970cc 4-cylinder, 4 stroke, water cooling, inline, multiple spherical combustion chamber, overlapping camshaft, electronic fuel injection and electronic control ignition
Engine brand LIUZHOU WULING
Displacement 1.1L
Cooling WATER COOLED
Max horsepower 51.6HP, 38.5KW
Max torque 65.5mm
Max speed 90km/h
Climbing ability 55
Ignition electronic fuel injection and electronic control ignition
Max speed: 80km/h
Brake system (front/rear): Disk/Disk
Gearshift mode: Automatic clutch,five speeds,one neutral with inside reverse gear
Starting system ELETRICAL
Battery 12V/ 45AH
Carburetor brand SIEMENS
Engine oil API SP SAE 10W/30
Gear oil Gear oi GL
Transmission FIVE SPEEDS, ONE NEUTRAL
Driveline SHAFT
Driving wheel 2W
Suspension, front/rear TWO SUSPENSIONS
Brakes, front/rear DISC
Brake operation FOOT&HAND
Tires, front/rear "FRONT 28×10-14 REAR 28×12-14
FRONT 7×8-12 REAR 27×11-12"
Fuel capacity/type 30L
Weight,G.W./N.W. 700KG±5KG/600KG±5KG
Max load 280KG±5KG
Wheelbase 1720mm
OA L*W*H 3020×1840×1650 mm
Height to seat 520mm
Min ground clearance 35mm
Carton size 2.8×1.6×1.22m
The other carton size 2.8×1.15×1.22m
Steering angle 36
Quantity: "1),2 units/20″;4 units/40″;8 units/40HQ
2),4 units/20″;8 units/40″;16 units/40HQ"
Packing Size: "1),2860x1650x1250 mm
2),2860x1150x1250 mm"
