Specifications
Prod Model: |
CS-E7011 |
Markets: |
North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe |
Brake Type: |
Disc Brake |
Maximum Speed: |
<50 km/h |
Fuel: |
Electric |
Certification: |
CE |
Transmission System: |
Chain Drive |
Structure: |
Without Door |
Transmission Type: |
Automatic |
Product Description
A. Electric mini ATV with voltameter.
B. Motor: 500W /800W
C. E-ATV with front & reverse gear.
D. With CE.
1. Motor: 500W /800W, brush motor
2. Battery Spec.: 4PCS x 12V /20Ah
3. Charger: 110-240V/50-60Hz
4. Charge period: 8-11hours
5. Battery-life: 300 cycles
6. Rating-speed: ≤ 25km/h
7. Controller: 48V/500W
8. Product size: 1570 x 800 x 950mm
9. Carton size: 1240 x 770 x 630mm
10. Wheelbase: 1065mm
11. Head light: 12V35W/35W
12. Brake system: Front/drum, rear/disc
13. Brake: Front/manual, rear/manual
14. Transmission: Chain
15. Hub: Iron
16. Suspension: Hydraulic suspension
17. G. W/N. W: 106kgs / 95kgs
18. Load capacity: ≤ 80kg
19. Tyre size: 145/70-6/145/70-6.
