Price: | US $ 1265/Piece |
---|---|
Trade Terms: | FOB,CIF,others |
Min Order: | 10/Piece |
Pay Type: | L/C,T/T |
Specifications
Prod Model: | D413 |
---|---|
Markets: | North America,South America,Eastern Europe,Southeast Asia,Oceania,Mid East,Eastern Asia,Western Europe |
Climbing Capacity: | 12 Degrees |
Running Distance: | 45-60KM |
Motor: | Brushless |
Max Speed: | <20km/h |
Battery Type: | Lead-acid Battery |
Frame Material: | Steel |
Voltage Of Battery: | 24V |
Power: | 501-800W |
Certification: | COC |
Maximum Loading Capacity: | ≥120kg |
Wheel Hub: | Alloy Hubs |
Folded: | Unfolded |
Charging Time: | >10h |
Part: | Motor |
Brake: | Front : Drum Rear : Drum |
Wheel Size: | 13" |
Product Description
Product DescriptionOverall Dimentions (LXWXH | 1460×720×1050mm |
Max Forward Speed | 12.5km/h |
Max Backward Speed | 2.4-4.8km/h |
Braking Distance(≤) | 2m |
Max Climbing slope | 12degrees |
Ground Clearance | 115mm |
Loading Capacity | 205kg |
Turning radius | 1.8m |
Range per Change | 50km |
Front Tire | 13" |
Rear Tire | 13" |
Motor Rated Power | 800w |
Controller | PG S-Drive 120A |
Charger | 24V 5A |
Battery | 12V/55AH X2 |
N.W. | 140kg |
G.W. | 155kg |
Battery Weight(2pcs) | 40kg |
Braking System | Electric Regenerative Braking |
Packing Size: | 1500x820x750mm |
Container packing | 20GP : 27units 40GP :57units 40HQ : 63units |
