Specifications
Product Description
We provide the 3% spare parts with free of charge after sale, and gurantee for one yeasr on engine.
Unit packing: (LxWxH):2070*720*1230 mm
Units per 40HQ: 38 pcs
Certificate: EEC, 3C
Can producing: 250cc, 150cc, 125cc
WL250T-38 | WL150T-38 | WL125T-38 | WL125T-38 |
L *W *H: 2070*720*1230 mm | L *W *H: 2070*720*1230 mm | L *W *H: 2070*720*1230 mm | L *W *H: 2070*720*1230 mm |
Wheelbase: 1530mm | Wheelbase: 1530mm | Wheelbase: 1530mm | Wheelbase: 1530mm |
Max speed: 105Km/h | Max speed: 80Km/h | Max speed: 75 Km/h | Max speed: 95 Km/h |
Dry weight: 162kg | Dry weight: 137kg | Dry weight: 134kg | Dry weight: 137kg |
Max Loading Weight(Kg): 165 | Max Loading Weight(Kg): 150 | Max Loading Weight(Kg): 150 | Max Loading Weight(Kg): 150 |
Front brake: disc by handle | Front brake: disc by handle | Front brake: disc by handle | Front brake: disc by handle |
Rear brake: disc by handle | Rear brake: disc by handle | Rear brake: disc by handle | Rear brake: disc by handle |
Front tyre: 130/60-13 | Front tyre: 130/60-13 | Front tyre: 130/60-13 | Front tyre: 130/60-13 |
Rear tyre: 130/60-13 | Rear tyre: 130/60-13 | Rear tyre: 130/60-13 | Rear tyre: 130/60-13 |
Fuel Capacity(L): 12L | Fuel Capacity(L): 12L | Fuel Capacity(L): 12L | Fuel Capacity(L): 12L |
Battery size(V/AH): 12V/9AH | Battery size(V/AH): 12V/7AH | Battery size(V/AH): 12V/7AH | Battery size(V/AH): 12V/7AH |
Engine: laying,1CYL,4stroke | Engine: laying,1CYL,4stroke | Engine: laying,1CYL,4stroke | Engine: laying,1CYL,4stroke |
Cylinder capacity: 249.5 ml | Cylinder capacity: 149.6 ml | Cylinder capacity: 124.6 ml | Cylinder capacity: 124.5 ml |
Bore x stroke: 69 *68mm | Bore x stroke: 57.4 *57.8mm | Bore x stroke: 52.4*57.8mm | Bore x stroke: 52.4 *57.8mm |
Max power: 12.4KW/7000r/min | Max power: 6KW/6900r/min | Max power: 5.3 KW/6900r/min | Max power: 7.0 KW/7300r/min |
Max torque: 20N/m/3800r/min | Max torque:9N/m/6000r/min | Max torque: 8N/m/6000r/min | Max torque:9N/m//6000r/min |
Cooling system: water cooled | Cooling system: air cooled | Cooling system: air cooled | Cooling system: water - cooled |
Start: electric and kick start | Start: electric and kick start | Start: electric and kick start | Start: electric and kick start |
Ignition: electronic CDI | Ignition: electronic CDI | Ignition: electronic CDI | Ignition: electronic CDI |
Qty (units)/40HQ/20QP: 34/8 | Qty (units)/40HQ/20QP: 34/8 | Qty (units)/40HQ/20QP: 34/8 | Qty (units)/40HQ/20QP: 34/8 |
