Specifications
Prod Model: |
168KT-3 |
Markets: |
North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe |
Age: |
Adults |
Maximum Speed: |
60-90 km/h |
Transmission: |
Chain |
Start-up: |
Manual Start-up |
Usage: |
Toy |
Kind: |
Gear |
Color: |
Red |
Condition: |
New |
Displacement: |
200cc/270cc |
Product Description
The SQ168KT-3 is composed by a frame realized with Ø 30 mm tubes. This model has BLACK & GOLDEN anodized components...E. G. Pedals, Bearing Hangers, Hubs, and Carriers, steering etc., professionally and neatly designed to satisfy our customers who want the best one for their hobbies. SQ168K-3T is equipped with 200CC 4-stroke, air force cooling (1/2 shift box) engine, and designed for passion, manufactured by enthusiasm with the ever-lasting pursuit for sense.
PRODUCT | RACING KART | MODEL | SQ-KT168-3(single seat) |
Engine | 4-stroke, air force cooling(1/2 shift box),200CC |
Horsepower | 6.5HP |
Braking form | Hydraulic vacuum disc |
Starting mode | Pull wire back kick start |
Fuel tank capacity | 7.5L |
tire size | 10*4.5-5(FR),11*7.1-5(RR) |
Brake Pump | Four piston |
Transmission mode | Chain transmission(428) |
Steering ratio | 1:1 |
Wheelbase | International standard1040MM |
axle | 30 |
Frame material | special alloy steel |
guardrail | special alloy steel 32 |
Bonding technology | Argon arc bonding technology |
guardrail | 12 fixed point |
Kart size | 185*130*63CM |
Net weight | 96KG |
Seat belts | three-point form |
STUB AXLE | M10 |
optional: | 5.5HP,9HP Engine |
PRODUCT |
RACING KART |
MODEL |
SQ-KT168-3(single seat) |
Engine |
4-stroke, air force cooling(1/2 shift box),200CC |
Horsepower |
6.5HP |
Braking form |
Hydraulic vacuum disc |
Starting mode |
Pull wire back kick start |
Fuel tank capacity |
7.5L |
tire size |
10*4.5-5(FR),11*7.1-5(RR) |
Brake Pump |
Four piston |
Transmission mode |
Chain transmission(428) |
Steering ratio |
1:1 |
Wheelbase |
International standard1040MM |
axle |
30 |
Frame material |
special alloy steel |
guardrail |
special alloy steel 32 |
Bonding technology |
Argon arc bonding technology |
guardrail |
12 fixed point |
Kart size |
185*130*63CM |
Net weight |
96KG |
Seat belts |
three-point form |
STUB AXLE |
M10 |
optional: |
5.5HP,9HP Engine |
