Specifications
Prod Model: |
SC2016A |
Markets: |
North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe |
Steel Painted Scooter: |
20 Inch |
Max Capacity: |
>100kg |
Kind: |
Single |
Height Adjustment: |
Height Adjustment |
Color: |
Black |
Wheels: |
2 |
Age: |
Children |
Wheel Material: |
Metal |
Certification: |
CE |
Condition: |
New |
Body Material: |
Steel |
Product Description
SPECIFICATION FOR SCOOTER (SC2016A)1.Frame: steel frame,H/T:30*34*200mm,T/T:42mm,D/T:25mm,TIG welding,end:3/8"
2.Fork: 20"MTB,steel,1-1/8" blades,stem:25.4*22.2*231*95mm
3.Front Brake: V-Brake arm shoes:60L
4.Rear Brake: V-Brake arm shoes:60L
5.Brake Lever: 2.5F lever & clamp,plastic
6.Brake Cable: only 2P
7.Handlebar: steel,BMX U style W/crossbar W:640mm R:180mm
8.H/Stem: four bolts bird handlebar w/stem D:22.2,L:220
9.Grips: PVC mushroom,L:110mm
10.Pad Set: PVC 2PCS for handlebar and stem with customer's design
11.Rims: alloy front 20"*1.75"*28H,rear 16"*1.75"*20H
12.Front Hub: steel 3/8"*28H*14G*95W*130mm
13.Rear Hub: steel 3/8"*28H*14G*95W*130mm
14.Spokes: steel 14G w/steel nipple
15.Tires: front 20"-1/2"*2-1/4",rear 16"-1/2"*2-1/4", rubber tires
16.Tube: front 20"*1.75" ,rear 16"*1.75",A/V tube
17.H/Parts: steel set of 8PCS
18.Footplate: plastic 320mm*50mm,BK
19.Stand: 16" steel 3.0T H:115mm
20.Mudguard: F/R steel painted long fender w/stay
21.Bell: nil
22.Carton: 5-PLY for export yellow
